If you are looking for a high quality and reliable servo but in a good price, you got the right one here. AGFrc A80BHMW V2 super torque waterproof steel gears digital servo will be the great option which support to use with high voltage and damp situation. A80BHMW V2 servo make almost 500oz-in torque with speed 0.11sec at 7.4V. While using voltage up to 8.4V, it can deliver 555oz-in super torque and 0.085sec high speed at 8.4V. Perfect for scale crawlers, 1/10 monster truck, 1/10 2WD and 4WD buggies, as well as 1/10 scale buggies and trucks. In addition, this A80BHMW V2 is great choice for boats and other application which require high power, high voltage and waterproof servo.
This A80BHMW V2 is waterproof IP67 level up to 1 meter which allow driving in the rain, puddles, snow and mud. High reliable and durable patent gear design which can be longer service life. Full aluminun CNC case for fast heat disppation. High precision digital control circuitry. If you need some modification based on our default setting, pls contact us directly.
Feature
Full CNC Aluminium Shell
Long Lifespan Brushless Motor
Strength 3 Ball Bearings
High Precision Steel Gears
Fully Waterproof Up To IP67 Grade
Built-in Magnetic Sensor
More robust 2mm PIN shaft
High Reliability Standard Digital Servo
Ideal for 1/10 On-Road, Off-Road, Truck, Plane, Robot and Engine etc.
Specification
A80BHMW V2
Operating Voltage: 4.8-8.4 V
Operating speed: 0.120sec/60° @ 6.0V
Operating speed: 0.100sec/60° @ 7.4V
Operating speed: 0.085sec/60° @ 8.4V
Stall Torque: 31 kg-cm (430 oz-in) @ 6.0V
Stall Torque: 36 kg-cm (499 oz-in) @ 7.4V
Stall Torque: 40 kg-cm (555 oz-in) @ 8.4V
Gear: Steel
Motor: BLS
Size: 40*20*37.5mm (1.57 x 0.78 x 1.47 in)
Weight: 81g
Connector Wire: TYU 300mm / 22AWG
